Description

Features

- Using 32 bit ARM CPU, operate on embedded -  LINUX OS, speed up to 200MHz
- Direct connection to PC via TCP/IP. Connection via TCP/IP converter is not required. Transmission speed up to 100 Mbps
- Control up to 8 doors via local door controller (BSDC)
- Storage Capacity up to 100,000 cards and 100,000 transactions
- Support ”Toggle Mode”, mainly use for controlling on/off of large-scale electrical equipment
- Support Anti-passback with confirmation by door open
- Support Anti-tailgating
- Support Arm/Disarm function
- Support Door Interlock function
- Using Flash Memory to store data. Data can be stored up till 10 years without power supply.
- Recoverable up to the latest 100,000 transaction if back end system failure
- Firmware Online Upgrade via TCP/IP
- Designed with communication line voltage auto-detection feature. Able to send fault alert should there be any line tamper/interruption
- Build-in with PLC function, simplify integration between security and control system
- Field programmable alarm monitoring function such as duress, panic, emergency, fire, intrusion etc..
- Smart Door Lock capability. When system detect door open and close back, door will automatically lock back
- Super user card functions. During system failure, make use of super user mode to open door
- Programmable Time zone / Pin Access Control
- Hot plugable Programming Keypad
- CE Certified
